Force Torque Sensor FTS-F

Short Description:

Force Torque Sensor FTS-F
Quick response
Small size
High precision with the principle of resistance strain type
Three parallel beam structure
Tiny long term crosstalk error, strong long-term stability.
Good temperature characteristics with self-compensated strain gauge

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Specification:

Nonlinearity	≤ 0.1 % F.S.	Repeatability	≤ 0.1 % F.S.
Zero Balance	± 5% F.S.	Operating temp range	-20～+60℃
Compensated temp rang	-10～+40℃	Insulation	≥ 2000 MΩ/50VDC
Recommended excitation	5-10VDC	Safe load limit	120 %F.S.
Temp effect on output	≤0.2 %F.S./10℃	Temp effect on zero	≤0.1 %F.S./10℃
Long term crosstalk error	≤3 %F.S.	Protection class	IP65
Cable Size	Φ3×4m
