Newest Design Bridge Column Type Load Cells ZTM
Short Description:
Newest Design Bridge Column Type Load Cells ZTM
Which is made of high quality alloy steel with high strength that it is strong enough to make sure the stable operation.
Compact construction, it has small size which takes up little space.
Equipped with a handle, it is convenient to use with simple operation which can help to save time and energy.
It is scientifically designed that it is suitable for vehicle and hopper scales and vehicle testing facilities.
Manufactured with strict requirements, Newest Design Bridge Column Type Truck Scale Load Cells has endurable servce life with the resistance to corruption, dust and oxygen that it can be used over and over again, which is quite cost effective.
Waterproof, it is easy to maintain and clean, extending its life circle. And it is available maintain same after the long-term use.
Developed by the international certification of CE, it has superior quality with elegant appearance and simple style.
Rated load:10T,20T, 30T, 40T
Main features: Alloy steel & stainless structure; bellows hermetically sealed by laser, nickel plated, waterproof and anti-corrosion, suitable for multiform environments; suitable for electronic platform scales, hopper scales, and other electronic weighing devies.
Whole multi column structure, novel and unique, high strength, good rigidity, anti-twist, whole structure, higher overload, anti-shock and anti-fatigue ,
small volume, light weight , exceeding tradition, fine interchangeability.
|
Specification |
||
|
Precison : C2 & C3 |
Temp. Effect on Span(%F.S/10℃): ±0.017& ±0.011 |
|
|
Comprehensive Error(%F.S) : ±0.03 & ±0.02 |
Temp. Effect on Zero(%F.S/10℃): ±0.029& ±0.019 |
|
|
Rated Output(mv/v) :2.0±0.01 |
Compensated Temp. Range(℃ ) : -10～+40 |
|
|
Creep(%F.S/30min) : ±0.023 & ±0.016 |
Use Temp. Range(℃ ) : -30～+70 |
|
|
Zero Balance(%F.S) : ±1.5 |
Excitation Voltage(V) :10～12(DC) |
|
|
Input Resistance(Ω) : 700±10 |
Safe Overload (%F.S) : 150 |
|
|
Output Resistance(Ω) : 700±5 |
Ultimate Overload (%F.S) : 200 |
|
|
Insulation Resistance(MΩ) : ≥5000(100VDC) |
Defend grade : IP68 |
|
