Stainless Steel Miniature Load Cells Sensor Force Transducer LWC
Short Description:
Stainless Steel Miniature Load Cells Sensor Force Transducer LWC
Feature:
Stainless Steel 17-4PH
Microstructure
Application:
It is widely used in force measurement applications in small installation space,
such as robot hand grip, pressure detection of hot and cold presses, and button feel testers.
Specification:
| Rated Load | 5-100kg |
| Sensitivity | 0.5-1.2mV/V |
| Accuracy Class | 1.0%F.S. |
| Zero balance | ±0.02 mV/V |
| Non-linearity | ±1%F.S. |
| Hysteresis | ±1%F.S. |
| Repeatability | ±1%F.S. |
| Creep (30mins) | ±1%F.S. |
| TCO | ±1%F.S/10℃ |
| TC SPAN | ±1%F.S/10℃ |
| Input resistance | 350±10Ω |
| Output resistance | 350±5Ω |
| Insulation resistance | ≥5000MΩ (50DVC) |
| Temperature Range. Compensated | -10～+40℃ |
| Operating Temp Range | -20～+60℃ |
| Safe load limit | 120%F.S |
| Over load limit | 150%F.S |
| Recommend excitation | 2.5-5V DC |
| Maximum excitation | 7V DC |
| Protection Class | IP65 |
| Construction | Stainless Steel |
| Cable: Length | Diameter:Ф3× 3m |
